Description Tube Assy OD×H: Φ 10x31.8 Connection Size /Thread Size:M12x0.75 2Way/3Way:2Way NO/NC:NC Seal Pad Size: Φ 8.6 AC/DC:AC Tube Assy Material:Copper Coil For Option:/ Please See PDF For More Details

Description Tube Assy OD×H:Φ9x25 Connection Size /Thread Size:M12x1 2Way/3Way:3Way NO/NC:NC Seal Pad Size:Φ4.3 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:ALTC079 Please See PDF For More Details

Description Tube Assy OD×H: Φ6×24.8 Connection Size/Thread Size: M10×1 2Way/3Way: 3Way NO/NC: NC Seal Pad Size: Φ3.2 AC/DC: DC Tube Assy Material: Stainless Steel Coil For Option: / Please See PDF For More Details

Description Tube Assy OD×H:Φ13×51.5 Connection Size/Thread Size:M16×1 2Way/3Way :2Way NO/NC :NO Seal Pad Size :Φ3.6 AC/DC:AC Tube Assy Material:Stainless Steel Please See PDF For More Details

Description Tube Assy OD×H:Φ10x31.7 Connection Size /Thread Size:M13x0.5 2Way/3Way:3Way NO/NC:NO Seal Pad Size:Φ5 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTH201 Please See PDF For More Details

Description Tube Assy OD×H:Φ10x26 Connection Size /Thread Size:M14x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ4.1 AC/DC:DC Tube Assy Material:Copper Coil For Option:ALTC285 Please See PDF For More Details

Description Tube Assy OD×H:Φ9x41.8 Connection Size /Thread Size:M12x0.5 2Way/3Way:3Way NO/NC:NC Seal Pad Size:/ AC/DC:AC Tube Assy Material:Copper Coil For Option:ALTH210 Please See PDF For More Details

Description Tube Assy OD×H:Φ8x109.5 Connection Size /Thread Size:M12x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ4.9 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:/ Please See PDF For More Details

Description Tube Assy OD×H:Φ9x41 Connection Size /Thread Size:M13x0.5 2Way/3Way:2Way NO/NC:NC Seal Pad Size: Φ5.5 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTC075 Please See PDF For More Details

Description Tube Assy OD×H:Φ9x25.1 Connection Size /Thread Size:M12x0.5 2Way/3Way:3Way NO/NC:NC Seal Pad Size: Φ4.4 AC/DC:AC Tube Assy Material:Copper Coil For Option:ALTH210 Please See PDF For More Details

Description Tube Assy OD×H:Φ8.8x29.5 Connection Size /Thread Size:M12x0.75 2Way/3Way:2Way NO/NC:NC Seal Pad Size: Φ4.4 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTC210 Please See PDF For More Details

Description Tube Assy OD×H:Φ9x27.7 Connection Size /Thread Size:M12x0.5 2Way/3Way:3Way NO/NC:NC Seal Pad Size: Φ4.7 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:/ Please See PDF For More Details

Description Tube Assy OD×H:Φ9x30 Connection Size /Thread Size:M12x0.5 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ5.1 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTH210 Please See PDF For More Details

Description Tube Assy OD×H:Φ10x33 Connection Size /Thread Size:M14x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ14.7 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTC285 Please See PDF For More Details

Description Tube Assy OD×H:φ10x28.4 Connection Size /Thread Size:M14x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:φ8.8 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTC285 Please See PDF For More Details

Description Tube Assy OD×H:φ10x28.6 Connection Size /Thread Size:M14x1 2Way/3Way:3Way NO/NC:NC Seal Pad Size:φ6.5 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:ALTC285 Please See PDF For More Details

Description Tube Assy OD×H:φ10x28.6 Connection Size /Thread Size:M14x1 2Way/3Way:3Way NO/NC:NC Seal Pad Size:φ5.5 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTC201 Please See PDF For More Details

Description Tube Assy OD×H: Φ 10x31.8 Connection Size /Thread Size:M12x0.75 2Way/3Way:2Way NO/NC:NC Seal Pad Size: Φ 8.6 AC/DC:AC Tube Assy Material:Copper Coil For Option:/ Please See PDF For More Details

Description Tube Assy OD×H:Φ9x25 Connection Size /Thread Size:M12x1 2Way/3Way:3Way NO/NC:NC Seal Pad Size:Φ4.3 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:ALTC079 Please See PDF For More Details

Description Tube Assy OD×H: Φ6×24.8 Connection Size/Thread Size: M10×1 2Way/3Way: 3Way NO/NC: NC Seal Pad Size: Φ3.2 AC/DC: DC Tube Assy Material: Stainless Steel Coil For Option: / Please See PDF For More Details

Description Tube Assy OD×H:Φ13×51.5 Connection Size/Thread Size:M16×1 2Way/3Way :2Way NO/NC :NO Seal Pad Size :Φ3.6 AC/DC:AC Tube Assy Material:Stainless Steel Please See PDF For More Details

Description Tube Assy OD×H:Φ10x31.7 Connection Size /Thread Size:M13x0.5 2Way/3Way:3Way NO/NC:NO Seal Pad Size:Φ5 AC/DC:AC Tube Assy Material:Stainless Steel Coil For Option:ALTH201 Please See PDF For More Details

Description Tube Assy OD×H:Φ10x26 Connection Size /Thread Size:M14x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ4.1 AC/DC:DC Tube Assy Material:Copper Coil For Option:ALTC285 Please See PDF For More Details

Description Tube Assy OD×H:Φ9x41.8 Connection Size /Thread Size:M12x0.5 2Way/3Way:3Way NO/NC:NC Seal Pad Size:/ AC/DC:AC Tube Assy Material:Copper Coil For Option:ALTH210 Please See PDF For More Details

Description Tube Assy OD×H:Φ8x109.5 Connection Size /Thread Size:M12x1 2Way/3Way:2Way NO/NC:NC Seal Pad Size:Φ4.9 AC/DC:DC Tube Assy Material:Stainless Steel Coil For Option:/ Please See PDF For More Details
We specialize in the deep customization of high-performance solenoid pilots, solenoid coils, and complete assemblies. Leveraging profound industry expertise and engineering capabilities, we deliver precisely tailored solutions for your specific application scenarios—from demanding industrial environments to precision fluid control systems.
Ningbo Anlite Machinery Co., Ltd has a R&D team of more than 30 mechanical,electrical and industrial automation design engineers, who develop an average of more than 50 new products per year. Our product innovation capability has been continuously improved, and our technical level has always been in line with international standards.
|
